Car fuel tank reverse design

Release time：2024-04-08 Views：436

With the development of the automobile industry and the revitalization of the domestic automobile industry, the demand for automobile fuel tanks by major automobile manufacturers has shown an obvious growth trend. A well-known automobile manufacturer in Tianjin hopes to conduct a three-dimensional scan of the Mercedes-Benz G500 fuel tank, obtain high-precision three-dimensional data, and then process it through post-processing software to conduct product reverse design and shorten the development process of new products.

Facing problems

1. The customer hopes to scan the Mercedes-Benz fuel tank in the factory workshop, so he has high requirements for the portability and stability of the 3D scanning equipment.

2. The customer's original method of collecting vehicle fuel tank data is manual measurement, which is not very accurate and slow.

3. The quality of the automobile fuel tank directly affects the overall performance and safety performance of the automobile, and the accuracy of the three-dimensional data obtained from the automobile fuel tank is required to be high.

Solution

Based on the problems faced by customers, HOLON3D engineers proposed a solution. They used the camera-type 3D scanning HL-3DX to 3D scan the Mercedes-Benz G500 fuel tank to quickly obtain the 3D data of the Mercedes-Benz fuel tank. Not only did the data have high accuracy, but the scanning speed was fast and the combination of 3D reverse software was successful. Complete the overall scanning of the workpiece, which improves the efficiency of later product reverse design and new product development, saves costs, and meets the customer's scanning needs.
