3D inspection of super large rigid castings

The vibrating screen equipment works by the reciprocating rotary vibration generated by the vibration of the vibrator, which produces the multi-spin type vibration of the screen surface. The work is complicated and demanding, and it is easy to wear. It requires daily maintenance and regular maintenance and overhaul to ensure production. The normal operation. A domestic customer needs to carry out three-dimensional inspection of the vibrating screen equipment. As the world's second largest casting, the vibrating screen is large and high. Scanning is a big project. After the customer has learned the data obtained by the Hualang 3D scanner. I feel very satisfied and purchase equipment.

More +
3D scanning and reverse modeling of a large snail shell

A 2.2-meter-diameter volute is a core component of large fluid equipment, and the accuracy of its spiral surface and overall structural integrity directly affect the fluid dynamics performance and operating efficiency of the equipment. The client needs to perform 3D scanning on this large volute to obtain precise, complete 3D data, which will be used to generate a CAD model through reverse engineering, providing a reliable basis for product replication, structural optimization, or spare parts production. Because the volute is large, has a complex curved structure, and the client has very high requirements for scanning accuracy and data completeness, traditional measurement methods are hard to meet these needs. Therefore, they chose the HOLON 3D Smart 49 handheld full-blue laser industrial-grade 3D scanner to provide efficient and precise technical support for the digital reverse engineering of the large volute.

More +
3D scanning of large turbine housings

"Our company leverages its technical strength to create original products that meet the era and market demands, and leads the market with continuously practiced and innovative technical solutions." The client is a well-known 'wind power group' both domestically and internationally, and they came seeking our technical solutions, using the brand-new 3D scanning technology to obtain 3D data of the new energy turbine nacelle.

More +
3D Check for Forklifts

Forklifts play a really important role in a company's logistics system and are the main force among material handling equipment. They're widely used in stations, ports, airports, factories, warehouses, and other sectors of the national economy. As a result, in recent years, the demand for forklifts in China has been growing by double digits every year.

More +
Diesel engine 3D scanning

A diesel engine is an internal combustion engine that mainly uses the combustion of diesel fuel to generate energy. It has the characteristics of high efficiency, high power and durability, and plays an important role in the fields of industry, transportation and agriculture. With the advancement of technology, the performance of diesel engines will be further improved. A well-known manufacturer uses a 3D scanner to perform 3D scanning and reverse modeling.

More +
Forklift body 3D scanning detection

A well-known enterprise production forklift truck, need to carry out three-dimensional detection of forklift truck body, with the traditional measurement method, time-consuming, can not detect all his data, in view of the above problems, Hualang three-dimensional for the enterprise to provide solutions.

More +
Three-dimensional inspection of wind turbine castings

With the continuous improvement, many aspects need to be improved. Fans are prone to problems under rated conditions. It is necessary to produce and manufacture fans in strict accordance with product standards. In the later stage, proper maintenance and maintenance are required to improve the service life of the fans. Data detection of the fan.

More +
Steam turbine 3D inspection

More +
CRCC 18th Bureau 13-Meter Precast Beam High-Precision Inspection

Railway construction, safety is paramount. Recently, Hualang 3D was commissioned by China Railway 18th Bureau to carry out high-precision quality inspection on a 13-meter precast concrete beam of a certain section they were building. The beam's left steel structure area was designed with a continuous embedded steel plate, serving as a key reference for the later installation of iron components. Since the beam can easily be impacted by external forces during multiple transports and hoisting, the steel plate is at risk of hidden deformations like warping, local dents, and edge bumps. If issues are discovered on-site during assembly in the traditional way, it could lead to serious schedule delays and rework costs. The client urgently needed an efficient method to precisely understand the actual shape of the steel plate before assembly and predict how well it would fit with the slot iron components. Hualang 3D used large-scale 3D scanning technology to carry out a comprehensive “digital check-up” of the precast beam.

More +
